DR 2020U

Where versatility & quality converge


Offering superior 2-sided scanning and at striking 600dpi, versatility truly meets quality in the DR 2020U. It is an ideal solution for decentralised scanning applications.
  • Connect with USB 2.0
  • Speed: up to 20ppm / 40ipm
  • Scan size: up to A4

Specifications for DR 2020U


Type Desktop ADF (Automatic Document Feeder) / flatbed scanner
Document Feeding Automatic sheet feeding / flatbed
Document size
Width: ADF: 140 - 216mm (5.5 - 8.5in.)
Flatbed: 216mm (8.5in.)
max. Business Card Feeder: 49 - 55mm (1.9 - 2.2in.)
Length: ADF: 100 - 356mm (3.9 - 14.0in.)
Flatbed: 297mm (11.7in.)
max. Business Card Feeder: 85 - 91mm (3.3 - 3.6in.)
Document thickness and weight 0.06 - 0.15mm, 52 - 128g/m2 (13 - 32lb. bond)
Card size and thickness
Feeding capacity 5.0mm stack including curls or 50 sheets of 80g/m2
Scanning element CCD (Charge-Coupled Device)
Light Source CCFL (Cold-Cathode Fluorescent Lamp)
Scanning Side Simplex / Duplex / Skip Blank Page
Scanning Modes Black and White, Error Diffusion, Advanced Text Enhancement (I/II), 256-level Grayscale, 24-bit Colour
Scanning Resolutions 100 x 100dpi, 150 x 150dpi, 200 x 200dpi, 240 x 240dpi, 300 x 300dpi,
400 x 400dpi, 600 x 600dpi
Scanning speed (A4 / LTR, Portrait, 200dpi)
Black and White Simplex: 20ppm
Duplex: 40ipm
256-level Grayscale Simplex: 20ppm
Duplex: 40ipm
24-bit Colour Simplex: 20ppm
Duplex: 40ipm
Interfaces Hi-Speed USB 2.0
Scanner driver ISIS / TWAIN
Software ISIS / TWAIN Driver, CaptureOnTouch, CapturePerfect 3.0, Adobe Acrobat Std, PaperPort, OmniPage, Biz Card Reader
Useful functions Double Feed Detection, User Registration, Advanced Text Enhancement, Skip Blank Page, Prescan, Auto Paper Size Detection, Deskew, Batch Separation, Text Orientation Recognition, Edge Enhancement, Preset Gamma Curve, Dropout Color (R/G/B), Color Enhancement (R/G/B), Border Removal, Punch Hole Removal, Separate Front & Back settings (Contrast / Brightness / Gamma correction, etc.)
Power requirements AC100 - 240V (50 / 60Hz)
Power Consumption Scanning: Max. 33.0W
Sleep mode: Max. 3.7W
Power Turned Off: 0.5W
Operating Environment 10 - 32.5°C (50 - 90.5°F)
Humidity: 20 - 80% RH
Dimensions (W x D x H) With paper guide closed: 440 x 400 x 180mm (17.3 x 15.8 x 7.1in.) *Without ADF cable
Weight Approx. 7.8kg (17.2lb.)
Options / Consumables Feed Roller Unit, Separation Pad.

Specifications are subject to change without notice.

Auto Power On / Off
  Energy efficiency is improved by the scanner automatically switching On or Off depending on the status of the connected PC.
